DISC Alesis MultiMix 6 USB, 6-channel, USB Mixer

Full Description

The MultiMix 6 USB mixer has six input channels, all of which can accept a 1/4" line input. You can can plug XLR microphones into channels one and two, including condensers thanks to the mixer's switchable 48V phantom power supply. You can also plug a guitar or bass directly into channel one's switchable high-impedance input.

Channels one and two offer switchable high-pass filtering at 75Hz to eliminate low-frequency rumble, handling and wind noise. Each channel has a pan control and channels one, two, three, and four provide high and low-shelving EQs. Channels one and two have independent gain trims, while channels three/four and five/six are configured as stereo pairs at the level and pan controls.

The MultiMix 6 USB has a two channel, five stage, multicolor LED meter for visual monitoring the main output level. A stereo, 1/4" headphone output has its own level control.

With flexible inputs for mic, line, and guitar-level sources, and a built-in USB computer recording interface, the MultiMix 6 USB is the compact choice for full-fledged mixing and recording.

FEATURES/SPECIFICATIONS:

• Six-channel mixer with mic, line, and guitar-level inputs
• 16-bit, 44.1 kHz stereo USB output on USB for easy Mac and PC interface
• Six 1/4-inch line-level inputs for instruments
• Two XLR inputs with gain trim, switchable high-pass filters, and 48V phantom power
• High-impedance guitar input for direct-connecting guitars
• Two-channel EQ on channels 1, 2, 3, and 4
• Multicolor LED metering for visual level feedback
• Main and headphone outputs with independent level controls
• Class compliant, plug-and-play USB for Mac and PC interface without installing drivers

• MultiMix 6 USB mixer
• USB cable
• Power supply
• Quick start guide

• Mac: OS X
• PC: Windows XP, Vista, or 7
• USB port

• Inputs:

• Line (CH 1, 2): 10 KΩ input impedance

• 5.5 mV ~ 4.9 V RMS sensitivity for max output
• Mic (CH 1, 2): 600 Ω input impedance balanced
• 700 mV RMS sensitivity for max output
• Line (CH 3, 4, 5, 6): 700 mV RMS sensitivity for max output

• HPF (CH 1, 2): 200 Hz (-1 dB), 80 Hz (-3 dB), 20 Hz (-24 dB)

• Outputs:

• Line: 7 V RMS max

• Headphone:** 0.5 W into 47 Ω

• Signal-to-noise Ratio: Line: > 92 dB (max output; JIS A-weighted) Mic: > 62 dB

• Distortion: < 0.02%
• Frequency Response: Line: 20 Hz - 20 kHz (± 0.5 dB), Mic: 20 Hz - 15 kHz (± 0.5 dB)
• Channel Equalizer: Bass: ± 14 dB @ 80 Hz, Treble: ± 14 dB @ 12 kHz
• Channel Fader Kill: > 90 dB @ 1 kHz
• Crosstalk: > 85 dB @ 1 kHz
• Interface: USB1.1 or higher (stereo in and stereo out)
• Power Adapter: 10 V AC, 500 mA
