Key Features
- 8-bit sampler for retro sounds
- Record directly into it with audio input
- Load wavetables using MIDI cables
- Save recorded samples to computer using MIDI
Doepfer A-112 Sampler / Wavetable Module Overview
The Doepfer A-112 is a voltage controlled sampler and wavetable oscillator. This module emulates early 8 bit samplers and is ideal if you're looking to expand your sounds in a retro style. The module can also work as a wavetable oscillator with the option to load wavetables with the midi ports. An exciting possibility of this is that you can use standard samples in wavetable mode and create interesting sounds and textures by stepping through.
Product Ref: 220518
Full Description
View Full DescriptionSampler
The A-112 samples at an 8-bit resolution, giving samples a retro sound to them. There are two banks of samples and you can record audio directly into this module. There is memory on board to store samples after you turn the module off. A gate can be used to play the sample and the sample will play as long as the gate is high, so you could patch a square wave in with the pulse width being modulated to create variable sample lengths. You can also manually play the sample by pressing the manual trig button. There are also some effects included like delays, freeze, reverse delay and pitch shifting.
Wavetable
The second mode of this module is wavetable mode. In this mode, the input you would've recorded audio into now becomes a control for moving through the wavetable. Wavetables can be loaded to the module by using MIDI dump. This works very much like a lot of other wavetable synths. What makes this interesting is the fact you can use a recorded sample as a wavetable. This makes for a very exciting opportunity for experimentation and some interesting uses. For example recorded speech can be used and individual vowel sounds can be picked out if you use other modules such as LFOs and attenuators. This mode also presents some interesting uses for external control modules like ribbon controllers.
Specifications
- Width: 10HP/50.5mm
- Depth: 100 mm (Measured from the rear side of the front panel)
- Current:
- +12V: +50mA
- -12V: -20mA
- Product Code: A-112v
