Key Features
- Stereo diode-bridge compressor and limiter
- Analog warmth from custom-built Midas input and output transformers
- Ideal for mixing, mastering, and broadcasting, with discrete signal path
- Broad range of compression ratios and switchable attack times
Behringer 369 2-Channel Stereo Compressor and Limiter - Nearly New Overview
The Behringer 369 2-Channel Stereo Compressor and Limiter is a legendary piece of equipment based on the classic diode-bridge design which became popular in the 70's. With its custom-built Midas input and output transformers, this compressor and limiter provide a professional-grade signal path. Ideal for mixing, mastering, and broadcast applications, this compressor offers a broad selection of compression ratios, ranging from 1.5:1 to 6:1. It features switchable attack time and recovery time presets, allowing you to customize the compression to fit your needs. The dedicated threshold selector and variable makeup gain settings provide even more control and flexibility.
Whether you prefer linked stereo mode or dual mono compression, this compressor gives you the choice. Its vintage-style gain reduction meters and transformer-balanced inputs and outputs ensure accurate monitoring and high-quality audio. Built with durability in mind, the Behringer 369 comes in a rugged 2U rackmount chassis, making it perfect for portable applications. Additionally, the auto-ranging universal switch-mode power supply ensures reliable performance no matter where you are.
Nearly New: This product may have been opened for quality control purposes, returned by a customer, refurbished, or may have non-essential parts or software missing. Otherwise, the product operates as new. This is a great opportunity to buy a fully functioning product at a discounted price.
Product Ref: 318394
Full Description
View Full DescriptionLegendary stereo compressor and limiter
The Behringer 369 is a classic 2-channel stereo compressor and limiter that is based on a revered form of compression circuitry called the diode-bridge compressor. These units have been trusted by audio professionals for decades and are known for their exceptional sound quality, character, and smoothness. With stereo and dual mono operating modes, the 369 is ideal for instrument buses, full mixes, or compressing two separate mono sources at once.
Custom-built Midas transformers
The 369 boasts custom-built Midas input and output transformers. These transformers are meticulously designed to provide a pristine and transparent signal path, ensuring the highest level of audio fidelity. With the Midas transformers, you can expect exceptional sonic performance and a rich, full-bodied sound that enhances your music or audio productions, adding a touch of saturation at higher input and output levels for that warm analog clipping that can bring character to anything.
Tweakable compression
The 369 offers a broad selection of compression ratios, allowing you to tailor the dynamics of your audio with precision. Choose from compression ratios of 1.5:1, 2:1, 3:1, 4:1, or 6:1, depending on your specific needs. With switchable attack times from slow to fast, the 369 gives you complete control over the transients in your audio. The compressor recovery time ranges from 100 to 1,500 milliseconds, giving you the flexibility to shape the release of the compression. Additionally, the limiter recovery time ranges from 50 to 800 milliseconds, ensuring precise control over the peak levels in your audio. With two auto-release presets for both the compressor and limiter, this processor is as fast and flexible as you need it to be.
Features
- Two-channel compressor and limiter based on a vintage 70's diode-bridge compressor
- Custom-built Midas transformers for warmth and depth of sound with reduced noise
- Fully discrete signal path for high-quality sound in mixing, mastering, and broadcasting
- Wide range of selectable ratios, from 1.5:1 to 6:1
- Switchable attack time for a wide range of material
- Separate compressor and limiter recovery time settings with auto-release presets
- Adjustable separate thresholds on compressor and limiter
- Variable makeup gain on both compressors for extra volume and grit
- Individual bypass on compressors and limiters
- Linked stereo or dual mono operation
- Two vintage-style gain reduction meters for monitoring levels
- Neutrik XLR connectors on input and output
- Durable 2U rackmount chassis is ready for installation in studios, and portable racks for live and broadcast use
- Auto-ranging universal power supply with switch mode for operation all over the world
Specifications
- Product Code: 369
- Audio Inputs:
- Type: 2x XLR, Transformer Balanced
- Impedance: 10 kΩ Default / 600 Ω Internal Option
- Max. Input Level: > +26 dBu
- Audio Outputs:
- Type: 2x XLR, Transformer Balanced
- Impedance: < 75 Ω Balanced
- Max. Output Level: > +26 dBu with 600Ω Load
- System Specifications:
- Frequency Response: 20 Hz to 20 kHz, ±0.5 dB
- Distortion (THD+N): < 0.03%, 50 Hz - 20 kHz, +4 dBu, Compressor & Gate In, Attack = Slow
- Noise: -79 dBu, 22 Hz - 22 kHz Unweighted, Compressor & Gate In, Attack = Slow
- Circuit: Discrete Class-A
- Limiter:
- Threshold: 2x Rotary Switches, +4 dBu to +15 dBu in 0.5 dBu Steps
- Recovery: 2x Rotary Switches, 50 ms, 100 ms, 200 ms, 800 ms, a1 100 ms – 2 s, a2 50 ms – 5 s
- Limit In/Out: 2x Toggle Switches
- Attack Fast/Slow: 2x Toggle Switches, Fast = 2 ms. Slow = 4 ms
- Compressor:
- Threshold: 2x Rotary Switches, +4 dBu to +15 dBu in 0.5 dB Steps
- Recovery: 2x Rotary Switches, 100 ms, 400 ms, 800 ms, 1500 ms, a1 100 ms – 2 s, a2 50 ms – 5 s
- Gain: 2x Rotary Switches, 0 dB to +20 dB in 2 dB Steps
- Ratio: 2x Rotary Switches, 1.5:1, 2:1, 3:1, 4:1, 5:1
- Comp In/Out: 2x Toggle Switches
- Attack Fast/Slow: 2x Toggle Switches, Fast = 3 ms. Slow = 6 ms
- Gain Reduction Meters: 2x Analogue Meters, 0 dB to 20 dB
- Controls:
- Bypass/In: 2x Toggle Switches, True Relay Bypass
- Mono/Stereo: Toggle Switch, Stereo Mode Links the Sidechains Together
- Internal/External: Toggle Switch, Internal = Local Switch Control, External = Remote Control
- External Control Connector: 15 Pin Female D Connector for Remote Control of Bypass, Mono/Stereo, Sidechain Link
